OUTBOARD INSTALLATION
119
2. Fit the throttle cable through the rubber grommet.
a
b
28491
a - Rubber grommet b - Throttle cable
3. Attach the throttle cable to the throttle lever with a cotter pin
retainer.
4. Adjust cable barrel until the barrel slips onto the mounting
stud.
5. Fasten the throttle cable to the mounting stud with a flat
washer and locknut. Tighten the locknut to the specified
torque.
28494
b
a
c
d
e
a - Throttle cable
b - Cotter pin retainer
c - Flat washer
d - Locknut
e - Cable barrel
Description Nm lb. in. lb. ft.
Throttle cable locknut 6 53

Mercury 50 4-Stroke Specifications

General

Engine Type	4-Stroke
Horsepower	50 hp
Cylinders	3
Starting System	Electric
Steering	Remote
Displacement	747 cc
Fuel Induction System	EFI
Alternator Amp	18 amp
Shaft Length	20 in
Full Throttle RPM Range	5000-6000 RPM
WOT Range	5000-6000 RPM
Fuel Tank Capacity	External Tank Required
