MAINTENANCE
Page 1D-12 90-888465 JUNE 2002
Shift Cable Installation
Install cables into the remote control following the instructions provided with the remote control.
NOTE: Install the shift cable to the engine first. The shift cable is the first cable to move when
the remote control handle is moved out of neutral.
N
1. Position remote control into neutral.
2. Shift outboard into neutral.
3. Align the shift pin with the center mark.
NRF
a
b
a-Shift Pin
b-Center Mark

Mercury Four Stroke Specifications

General

Engine Type	4-Stroke
Fuel Induction System	Electronic Fuel Injection (EFI) or Carbureted, depending on model
Starting System	Manual, Electric
Steering	Tiller, Remote
Alternator	Varies by model
Full Throttle RPM Range	Varies by model
Weight	Varies by model
Gear Ratio	Varies by model
Warranty	Varies by region and model (e.g., 3 to 5 years)
Cylinders	1 - 6
Shaft Length	15", 20", 25"
