Mercury INSTALLATION MANUAL D7.3L D-TRONIC - Page 71

D7.3L D-TRONIC DIESEL ENGINES - BRAVO MODELS
Page 71 of 90
4. Rotate trim position sender as required to show full DOWN/IN position on dashboard
instrument as shown.
71671
a
a-Trim Gauge Needle
5. Tighten retaining screws and turn ignition key to the “OFF” position.
71220
a
b
a-Retaining Screws
b-Trim Position Sender
