Mercury XR2 User Manual

11
ob
GENERAL INFORMATION
Courtesy of ABYC
1
ob
Exhaust Emissions
BE ALERT TO CARBON MONOXIDE POISONING
Carbon monoxide is present in the exhaust fumes of all internal com-
bustion engines including the outboards, stern drives and inboard
engines that propel boats, as well as the generators that power vari-
ous boat accessories. Carbon monoxide is a deadly gas that is odor-
less, colorless and tasteless.
Early symptoms of carbon monoxide poisoning which should not be
confused with seasickness or intoxication, include headache, dizzi-
ness, drowsiness, and nausea.
WARNING
!
Avoid the combination of a running engine and poor ventila-
tion. Prolonged exposure to carbon monoxide in sufficient
concentration can lead to unconsciousness, brain damage, or
death.
GOOD VENTILATION
Ventilate passenger area, open side curtains, or forward hatches to
remove fumes.
1 Example of desired air flow through the boat.

Mercury XR2 Specifications

General

MODEL	XR2
Horsepower	180 (134kw)
Propshaft Kilowatts1	194
Full Throttle RPM Range	6000-7000
Idle RPM in Forward Gear	650-750
Maximum Timing	25° BTDC
Idle Speed Pickup Timing	2° ATDC
Gear Ratio	1.87:1
Piston Displacement	122 cu. in. (2.0L/1998cc)
Bore	3.125 in. (79.5 mm)
Stroke	2.65 in. (67 mm)
Firing Order	1-2-3-4-5-6
Recommended Spark Plug	NGK-BUHW (P/N 33-97180)
Fuel Pressure	5 - 6 psi
Recommended Gasoline	Refer to Fuel Section
Recommended Oil	Refer to Fuel Section
Recommended Gear Case Oil	Quicksilver Hi-Performance Gear Lube (92-816026A4)
Gear Case Lubricant Ca- pacity	22.5 fl. oz. (666 ml)
Charging System Output	16 amps @ 7000 RPM
Battery Rating	Minimum reserve capacity rating of 100 minutes and CCA of 350
Water Pres. @ WOT	15 PSI (103.4 kPa)

Weight and Dimensions

Weight	350 lbs. (159 kg)
Transom Height	Short Shaft = 15” (381mm) Long Shaft = 20” (508mm)
