Mercury XR2 User Manual

47
MAINTENANCE
12
4–53
N
ohl8
Propeller Replacement
WARNING
!
If the propeller shaft is rotated while the engine is in gear, there
is the possibility that the engine will crank over and start. To
prevent this type of accidental engine starting and possible
serious injury caused from being struck by a rotating propel-
ler, always shift outboard to neutral position and remove
spark plug leads when you are servicing the propeller.
1 Shift outboard to neutral (N) position.
2 Remove spark plug leads to prevent engine from starting.
3 Straighten the bent tabs on the propeller nut retainer.
4 Place a block of wood between gear case and propeller to hold
propeller and remove propeller nut.
5 Pull propeller straight off shaft. If propeller is seized to the shaft
and cannot be removed, have the propeller removed by an au-
thorized dealer.
IMPORTANT: Use care to prevent losing forward thrust washer
(located between propeller and gearcase) when removing pro-
peller.

Mercury XR2 Specifications

General

MODEL	XR2
Horsepower	180 (134kw)
Propshaft Kilowatts1	194
Full Throttle RPM Range	6000-7000
Idle RPM in Forward Gear	650-750
Maximum Timing	25° BTDC
Idle Speed Pickup Timing	2° ATDC
Gear Ratio	1.87:1
Piston Displacement	122 cu. in. (2.0L/1998cc)
Bore	3.125 in. (79.5 mm)
Stroke	2.65 in. (67 mm)
Firing Order	1-2-3-4-5-6
Recommended Spark Plug	NGK-BUHW (P/N 33-97180)
Fuel Pressure	5 - 6 psi
Recommended Gasoline	Refer to Fuel Section
Recommended Oil	Refer to Fuel Section
Recommended Gear Case Oil	Quicksilver Hi-Performance Gear Lube (92-816026A4)
Gear Case Lubricant Ca- pacity	22.5 fl. oz. (666 ml)
Charging System Output	16 amps @ 7000 RPM
Battery Rating	Minimum reserve capacity rating of 100 minutes and CCA of 350
Water Pres. @ WOT	15 PSI (103.4 kPa)

Weight and Dimensions

Weight	350 lbs. (159 kg)
Transom Height	Short Shaft = 15” (381mm) Long Shaft = 20” (508mm)
