Mercury XR2 User Manual

18
ob
GENERAL INFORMATION
1
23
4
5
6
7
8
9
10
12
7
11
13
Component Identification
1. Top Cowl 8. Transom Brackets
2. Cowl Latch
B Cl
9. Trim Adjustment Bolt
G C
3. Bottom Cowl
4Wt P Idit H
10. Gear Case
11 W t Di h
4. Water Pump Indicator Hose
(
Tell-Tale
)
11. Water Discharge
12 Cooling Water Intake Holes
(Tell Tale)
5. Drive Shaft Housing
12.
C
oo
li
ng
W
ater
I
nta
k
e
H
o
l
es
13 Skeg
5. Drive Shaft Housing
6. Anti-Ventilation Plate
13
.
Sk
eg
7. Corrosion Anode

Mercury XR2 Specifications

General

MODEL	XR2
Horsepower	180 (134kw)
Propshaft Kilowatts1	194
Full Throttle RPM Range	6000-7000
Idle RPM in Forward Gear	650-750
Maximum Timing	25° BTDC
Idle Speed Pickup Timing	2° ATDC
Gear Ratio	1.87:1
Piston Displacement	122 cu. in. (2.0L/1998cc)
Bore	3.125 in. (79.5 mm)
Stroke	2.65 in. (67 mm)
Firing Order	1-2-3-4-5-6
Recommended Spark Plug	NGK-BUHW (P/N 33-97180)
Fuel Pressure	5 - 6 psi
Recommended Gasoline	Refer to Fuel Section
Recommended Oil	Refer to Fuel Section
Recommended Gear Case Oil	Quicksilver Hi-Performance Gear Lube (92-816026A4)
Gear Case Lubricant Ca- pacity	22.5 fl. oz. (666 ml)
Charging System Output	16 amps @ 7000 RPM
Battery Rating	Minimum reserve capacity rating of 100 minutes and CCA of 350
Water Pres. @ WOT	15 PSI (103.4 kPa)

Weight and Dimensions

Weight	350 lbs. (159 kg)
Transom Height	Short Shaft = 15” (381mm) Long Shaft = 20” (508mm)
