General| MODEL | XR2 |
|---|---|
| Horsepower | 180 (134kw) |
| Propshaft Kilowatts1 | 194 |
| Full Throttle RPM Range | 6000-7000 |
| Idle RPM in Forward Gear | 650-750 |
| Maximum Timing | 25° BTDC |
| Idle Speed Pickup Timing | 2° ATDC |
| Gear Ratio | 1.87:1 |
| Piston Displacement | 122 cu. in. (2.0L/1998cc) |
| Bore | 3.125 in. (79.5 mm) |
| Stroke | 2.65 in. (67 mm) |
| Firing Order | 1-2-3-4-5-6 |
| Recommended Spark Plug | NGK-BUHW (P/N 33-97180) |
| Fuel Pressure | 5 - 6 psi |
| Recommended Gasoline | Refer to Fuel Section |
| Recommended Oil | Refer to Fuel Section |
| Recommended Gear Case Oil | Quicksilver Hi-Performance Gear Lube (92-816026A4) |
| Gear Case Lubricant Ca- pacity | 22.5 fl. oz. (666 ml) |
| Charging System Output | 16 amps @ 7000 RPM |
| Battery Rating | Minimum reserve capacity rating of 100 minutes and CCA of 350 |
| Water Pres. @ WOT | 15 PSI (103.4 kPa) |
Weight and Dimensions| Weight | 350 lbs. (159 kg) |
|---|---|
| Transom Height | Short Shaft = 15” (381mm) Long Shaft = 20” (508mm) |
