Quickstart Guide : Appendix II I/O Daughter-card Options
Page 79
TASCAM TDIF
The TASCAM TDIF daughter card offers 24 channels of I/O over 3 Tascam TDIF connections. Connection is via three
DB-25 connectors, One on the main card attached to the Mykerinos and two more on a separate bracket con-
nected via internal ribbon cable to the main card.
TASCAM TDIF I/O Option
A TASCAM TDIF format option bracket may be added to the ADAT I/O daughtercard and provides is available for 8
channels of TDIF I/O. The TDIF bracket connects to a socket on the ADAT card only. This daughter card cannot be
used in multi-board systems (since it utilizes the HTDM connector).
