Merida CENTURION - Recommended Torque Settings for Disc Brakes and Hydraulic Rim Brakes

103
Component Bolted connections Shimano
1
(Nm) SRAM/Avid
2
(Nm) Tektro
3
(Nm) TRP
4
(Nm)
Pedal Pedal axle 35
Shoe Cleat 5 - 6
Spike 4
Brake (V-brake) Cable clamp 6 - 8 6 - 8 6 - 8 6 - 8
Brake shoe mount 6 - 8 6 - 8 6 - 8 6 - 8
Brake pad fixing 1 - 2
Brake boss frame/fork 8 - 10
1
www.shimano.com
2
www.sram.com
3
www.tektro.com
4
www.trpbrakes.com
Recommended torque settings for disc brakes and hydraulic rim brakes
Component Shimano
1
(Nm) Avid
2
(Nm) Tektro
3
(Nm) TRP
4
(Nm) Magura HS
5
(Nm)
Brake caliper mount on frame/fork 6 - 8 9 - 10 (IS adapter) 6 - 8 6 - 8 6
8 - 10 (brake caliper)
Brake lever unit on handlebars
- Single-bolt clamp 6 - 8 Discrete Clamp Bolt/ 5 - 7 4
Hinge Clamp Bolt/
XLoc Hinge Clamp Bolt: 5 - 6
Pinch clamp bolt: 2.8 – 3.4
Split Clamp Bolts /
Match Maker Bolts: 3 - 4
- Two-bolt clamp 4 - 5
Union screws of cable at grip 5 - 7 5 4
and normal cable at brake caliper
Brake cable connector at
brake caliper (disc tube cable) 5 - 7
Expansion tank cap 0.3 - 0.5
Bleeding device brake caliper 4 - 6 4 - 6
