11
To raise the presser foot, raise the lever on the rear of
the machine until it engages.
10. OPTIONAL ACCESSORIES
* The following optional presser feet specially
prepared for this machine are available at
extra-charge.
Note: Do not use presser foot made for other
machines.
Use of such presser foot may result in
interference with the needle and knife and can
be hazardous.
* The snap-on type presser foot of this machine
permits easy removal and replacement.
Snap-on type presser foot
Removal
* Raise presser foot and raise needle bar to its highest
position.
* Press red colored lever (A) located on back of clamp
under the presser foot shank, raise presser bar lifter
to its High Lift position and while holding the presser
bar lifter in this position, remove the presser foot
plate.
Replacement
* Place presser foot plate on throat plate under presser
foot shank so that hinge pin (C) will fit inslot (B) of
the shank. Then lower presser bar lifter.
* If presser foot plate can not be placed under presser
foot shank easily, raise presser bar lifter to its High
Lift position and while holding it in this position,
place presser foot plate under presser foot shank.
Then lower presser bar lifter.
* Raise presser bar lifter and make sure the presser
foot plate is properly attached to the presser foot
shank.
9. PRESSER FOOT LIFER
Be sure to disconnect the power line plug or
turn off the power switch when changing the
presser foot.
B
C
A
