Merrylock MK740DSA User Manual

4.5
N
3.5
20
(13/64")
7 mm
(17/64")
5 mm
3 mm
(1/8")
5 mm
(3/16")
(10/64")
(15/64")
6.0 mm
4.0 mm
15. STITCH WIDTH ADJUSTMENTS
* Overlock seam width can be achieved by
repositioning the needle position and also with the
width adjustment knob.
(1) Width a
djustment by changing
needle position
* Overlock seam width can be adjusted by changing
the needle position.
(a) When using left needle............................6 mm
(15/64 inch)
(b) When only right needle is used...............4 mm
(10/64 inch)
(2) Width adjustment with adjustment knob
* Use of width adjustment knob will permit further
adjustment within the width range shown below.
(a) When using left needle........................5~7 mm
(13/64 ~ 17/64 inch)
(b) When only right needle is used...........3~5 mm
(1/8 ~ 3/16 inch)
(a) Left needle ( ) needleb Right
(a) Left needle ( ) needleb Rihgt
