31
Always unplug before re-lamping.
Be sure the light bulb has cooled off before
changing with a new one.
Replace the light cover first before connecting
the power line plug.
(4) How to exchange light bulb
* Light bulb is available at your dealer shop.
Take old bulb to the dealer shop and ask for same
bulb.
If voltage indicated on the electrical rating plate of*
your machine is 120V, ask for light bulb conforming
to following specification.
- Bayonet type: 110~120V, 15W
Glass shape: T-20*
* Lamp cap: E12
* Overall length: 48mm
* Remove light cover screw and while pushing the
cover lightly to the rear, swing cover to the left and
remove from machine as shown in the illustration.
Turn bulb to the left to remove.
To replace the bulb, push bulb into the socket and
turn to the right.
* If voltage indicated on the electrical rating plate of
your machine is 220-240V, ask for light bulb
conforming to following specification.
-Edison type (screw type): 220 ~240V, 15W
* Glass shape: T-22
* Lamp cap: E14
* Overall length: 56mm
* Remove light cover screw and while pushing the
cover lightly to the rear, swing cover to the left and
remove from machine as shown in the illustration.
Turn bulb to the left to remove. To replace the bulb,
screw bulb into the socket and turn to the right.
Replace
Remove
A
