74 Meru Access Point Installation Guide © 2010 Meru Networks, Inc.
Installation Requirements
AP150 Installation Items
You need the tools listed below.
Installation Type Consumable Items Required
Horizontal mounting None
Vertical mounting over a wall stud
Two #6 x 2" wood screws for a wood stud; or
Two #6 x 1½” metal screws for a metal stud
Mounting bracket
Vertical mounting on sheetrock
Two #6 x 1" screws
Two #4-6 x 7/8” ribbed plastic wall anchors
Mounting bracket
Horizontal mounting below a
hanging ceiling
Two caddy fasteners
Two plastic spacers
Two keps nuts (with attached lock washer)
Mounting bracket
Mounting above a ceiling tile
Two T -r ail c li ps
One T-box hanger
One bracket mounting clip
Mounting bracket
