Checking LED Activity
12. If needed, reposition the antennas. Be sure to loosen the ring at the base of the antenna before
repositioning, and retighten after.
13. Replace the ceiling tile in the ceiling brackets.
The AP100-P, with mounting bracket and light-pipe extender, installed above a ceiling tile is shown
in Figure 9:
Figure 9: AP100-P Installed Above Ceiling Tile
Checking LED Activity
After the AP100 is connected, the LEDs near the RJ-45 connector should light, as shown in Figure 10.
Figure 10: RJ-45 LEDs
The green LED on the left blinks if any Ethernet activity is taking place. If there is no Ethernet activity,
the LED is off. The LED on the right is solid yellow if an Ethernet link is present. If no Ethernet link
is present or connectivity is lost, the LED is off.
M
ounting bracket
A
ccess Point
S
ide view
C
eiling tile
Light pipe extender
00121
Ethernet activity
Link present
00129
