20 Meru Access Point Installation Guide
Installation Requirements
Figure 12: AP200 Mounting Bracket
Installation Requirements
The following recommended mounting locations provide the best reception for the AP200:
z On a horizontal surface, such as a table or a desk
z On a vertical surface, usually a wall
z Below a hanging ceiling
z Above a hanging ceiling tiles (this installation is supported only for the AP200 with the plastic
enclosure removed)
Suitable for use in environmental air space in accordance with the Section 300-22(c) of the
National Electric Code and Sections 2- 128.12 - 010 (3) and 12 - 100 of the Canadian Electrical
Code. Part 1. C22. 1. (For AP200 with plastic enclosure removed.)
To complete this installation, you need the items listed in Table 6.
Access point mount
Ceiling mount hole
ccess point mount
Access point mount
Locking detent
all cable access
uspended ceiling
able access
00100
