Installation Requirements
© 2010 Meru Networks, Inc. Installing AP300 15
The calculation for 802.3at PoE use looks something like this:
(Number of AP300s * 13watts) + (sum of all other PoE devices power requirements) <= switch
power provided
Installation Requirements
An array of holes on the mounting bracket allows the AP300 to be mounted on the wall and over junc-
tion boxes or molly bolts. There are holes for passing the PoE Ethernet or external power supply cable
through the bracket if the bracket is mounted on a junction box. A template of this bracket is included
in Appendix E of this guide.
The AP300 has a security cable slot so you can lock the AP300 with a standard security cable, such as
those used to secure laptop computers.
Purchase optional mounting kits to mount the AP300 either from the ceiling or inside an enclosure:
 Suspended Ceiling Rail Mounting Kit: ACC-MNT-SCRMKIT
 Above Suspended Ceiling Mounting Kit (T-Bar Hanger): ACC-MNT-ASCMKIT
 Inside a Hoffman Enclosure using Hoffman compatible mounting bracket: ACC-AP300-BHE (enclosure
not provided)
 Above hanging ceiling tiles. Suitable for use in environmental air space in accordance with the
Section 300-22(c) of the National Electric Code and Sections 2- 128.12 - 010 (3) and 12 - 100 of the
Canadian Electrical Code. Part 1. C22. 1.
To complete AP300 installation, you need the items listed below.
Installation Type Items Required
Horizontal mounting None
Vertical mounting over a wall
stud
 Two #6 x 2" wood screws for a wood stud; or
 Two #6 x 1½” metal screws for a metal stud
 Mounting bracket
Vertical mounting on sheetrock
 Two #6 x 1" screws
 Two #4-6 x 7/8” ribbed plastic wall anchors
 Mounting bracket
Horizontal mounting below a
hanging ceiling
 Two caddy fasteners
 Two plastic spacers
 Two keps nuts (with attached lock washer)
 Mounting bracket
