LED Array
Setup and Functioning
14
/
58
20.03.2015
8LE-D23_BA_E
I The electronic assembly for output control is damaged.
Off
M=Light-LED is either switched on, defective or is not supplied with operating voltage.
Figure 3: Lighting angles
The lighting angles are custom-specific, they can be identified via the M=Light Control software.
The angle set for the mounted LEDs is provided in the status display of the software (Figure 5):
