MESSRING M-LIGHT LED - Flash-Bus Switch-on Procedures; 8.2.1. Synchronizing with High-Speed Camera; 8.2.2. Triggering with Facility Control PLC

Handling
Switch-on of M=LIGHT LED via Flash-Bus
8LE-D23_BA_E
20.03.2015
53
/
58
8.2.1. Synchronizing the M=Light LED with the High-Speed Camera
Figure 31: High-speed camera connection
Item:
Description
1
M=Light LED IN
2
M=Light LED Bus Splitter
3
TTL-sync line from the camera
4
High-speed camera
8.2.2. Triggering M=Light LED with the Help of the Facility Control PLC
Item:
Description
1
M=Light LED IN
2
PLC
3
Potential-free output of the PLC (NO
contact).
Figure 32: PLC connection line
