Connect additional M=Light-LED accordingly.
For connection of the M=Light-LEDs, use patch cables according to CAT5 EIA/TIA-568 or
higher.
Specify a unique CAN-bus address for every M=Light LED in the same CAN-bus line.
Now, the signal connections have been completely established. The CAN-bus and Flash-bus
are automatically terminated by the internal terminating resistor of the M=Light LED last
connected.
