16. Technical Data
TKHS 315 C
2.8 DNB
TKHS 315 C
2.0 WNB
TKHS 315 C
3.1 WNB
Voltage 400 V / 3~50 Hz 230 V / 1~50 Hz 230 V / 1~50-60 Hz
Nominal current A 4.7 9.0 13.5
Fuse protection min. A 3-10 (time-lag) 1-16 (time-lag) 1-16 (time-lag)
Protection class IP 54 IP 54 IP 54
Motor speed min
-1
2778 2980 2950 (50 Hz) /
3580 (60 Hz)
Motor power
Power input P
1
Power output P
2
kW
kW
2.8 kW S6 40%
2.3 kW S6 40%
2.0 S6 40%
1.45 kW S6 40%
3.1 kW S6 40%
2.57 kW S6 40%
Saw blade cutting speed m/s 50 50 50
Riving knife thickness mm 2.5 2.5 2.5
Saw blade
saw blade diameter (outer)
saw blade hole (inside)
cutting width
max. base body thickness of the saw
blade
mm
mm
mm
mm
315
30
> 2.6
≤ 2.3
315
30
> 2.6
≤ 2.3
315
30
> 2.6
≤ 2.3
Cutting depth
saw blade vertical
at 45 saw blade tilt
mm
mm
0-85
0-60
0-85
0-60
0-85
0-60
Dimensions
Saw table length
Saw table width
Table extension length
Table extension width
Height (saw table)
Height (overall)
mm
mm
mm
mm
mm
mm
800
550
800
400
850
1050
800
550
800
400
850
1050
800
550
800
400
850
1050
Weight complete approx. kg 64.0 62.0 62.0
Guaranteed sound power level according to
DIN EN 1870-1 (2007)*
no-load
when sawing
Sound pressure level according to DIN EN
ISO 3746 (1995) and ISO 7960:1995 (E)*
no-load
when sawing
Uncertainty K
dB (A)
dB (A)
dB (A)
dB (A)
dB (A)
88.0
111.6
77.3
97.7
4.0
88.0
111.6
77.3
97.7
4.0
88.0
111.6
77.3
97.7
4.0
Ambient temperature range C –10 to +40 –10 to +40 –10 to +40
Extension cable – min. lead cross section
Length of cable: 10 m
Length of cable: 25 m
Length of cable: 50 m
mm
2
mm
2
mm
2
5 x 1.5
5 x 2.5
5 x 2.5
3 x 1.0
3 x 1.5
3 x 2.5
3 x 1.0
3 x 1.5
3 x 2.5
* The values stated are emission values and as such do not necessarily constitute values which are safe for the workplace.
Although there is a correlation between emission levels and environmental impact levels, whether further precautions are neces-
sary cannot be derived from this. Factors influencing the actually present environmental impact level in the workplace include the
characteristics of the work area and other noise sources, i.e. the number of machines and other neighbouring work processes.
The permitted workplace values can likewise vary from country to country. This information is intended to assist the user in esti-
mating hazards and risks.
