Metal Samples MS2601E - Page 30

HAZARDOUS AREA SAFE AREA
Current Loop Supply (24V Dc)
from PLC/DCS/PSU/....
Control Drawing
MS26X1E / MS29X1E
ER Transmitter
EXWDB-00009611
CRT
BP
MS2601E/MS2651E/MS2901E/MS2951E HIGH RESOLUTION ER
4-20mA TRANSMITTER
F
23
V(-)
V(+)
J2
J2
S1
21
S1
J2
ER Probe (Simple Device)
(Sold Separately)
OR
Probe Cable Assembly
(Sold Separately)
ER Probe (Simple Device)
(Sold Separately)
CN2
1
2
3
1
U
m
= 28V
V(+)
V(-)
MAXIMUM OUTPUT ENTITY PARAMETERS
AT CN2 - PROBE TERMINALS
U
O = 4.94 Vdc
I
O = 0.486 A
P
O = 0.42 W
04/15/20
EAN SAK LWB
