Technical specifications
26
Installation diagram CB316 & CB425
1. Water drain pipe, diam. 24mm
2. Cold water connection, diam 3/4” external thread
3. Electric connection
Look, Installation, place; Placing of appliance[316,425]
A
B
C
D
E
F
49 mm
151 mm
111 mm
196 mm
156 mm
232 mm
CB 316
CB 425
500 mm
6
9
0
m
m
5
8
0
m
m
500 mm
8
0
0
m
m
5
8
0
m
m
1
2
3
3
2
1
3
2
1
F
D
B
A
C
E
100 mm
- 0
+ 10
100 mm
- 0
+ 10
