Technical specifications
25
Installation diagram CB249
1. Water drain pipe, diam. 24mm
2. Cold water connection, diam. 3/4” external thread
3. Electric connection
Look, Installation, place; Placing of appliance[249]
A
B
C
D
E
F
49 mm
130 mm
111 mm
175 mm
156 mm
211 mm
390 mm
6
9
0
m
m
4
6
0
m
m
1
2
3
1
2
3
F
D
B
A
C
E
