Technical specifications
29
Installation diagram DSS42
1. Water drain pipe, diam. 24mm
2. Cold water connction, diam. 3/4” external thread
3. Electric connection
Look, Installation, place; Placing of appliance[42]
110 mm
A
B
C
D
E
F
49 mm
270 mm
111 mm
311 mm
156 mm
347 mm
500 mm
6
3
0
m
m
9
2
0
m
m
1
2
3
F
D
B
A
C
E
3
2
1
