Metos WD-211E ICS+ - Page 63

19.9.2003 Rev. 1.0
Spare parts
57
POS M-code Model Description W-code
Drying zone Lower part, Optional equipment
1 5320092 T-60 Door 600mm , Cpl Drying zone T-60 w23314,75
1 5320093 T-90 Door 900mm , Cpl Drying zone T-90 w23315,75
2 5320237 Handle PECO P225/132 M8 w718,0842
3 w43534,31 Attachment magnet w43534,31
4 5315353 Magnet round 6x50 w602,0551
5320223 Rubber moulding Specify length w43995,31
w700,1808 Screw FRH M4x8 A2 w700,1808
w700,0230 Screw MCS6S M8x16 A2 w700,0230
5 w23480,75 T-60 Feeding cradle T-60 Drying zone T-60 w23480,75
5 w23480,76 T-90 Feeding cradle T-90 Drying zone T-90 w23480,76
6 w43499,01 T-60 Feeding bar T-60 Drying zone T-60 w43499,01
6 w43500,01 T-90 Feeding bar T-90 Drying zone T-90 w43500,01
7 w36483,01 Connector pipe w36483,01
w36457,75 Door locking , Cpl w36457,75
8 w36457,31 Door lock w36457,31
9 5320189 Stop lug w43517,31
10 5320184 Plate spring w43448,31
5320720 Screw RXS 4.2x13 A2 w700,0715
11 w43528,31 T-60 Fastening border door T-60 Drying zone T-60 w43528,31
11 w43529,31 T-90 Fastening border door T-90 Drying zone T-90 w43529,31
12 w742,4600 Sliding border kit , Cpl w742,4600
w43746,02 Fastening sliding border w43746,02
w43739,31 Sliding border w43739,31
w700,1205 Washer RBS 6.4x18 A2 w700,1205
w700,1404 Locking nut LM DIN 985 M6 A2 w700,1404
wACS121333 Screw MRX 4x6 A4 wACS121333
w700,0225 Screw MCS6S M6x12 A2 w700,0225
w700,1202 Washer BRB 4.3x12 A2 w700,1202
13 w43357,79 T-60 Guide pipe T-60 Drying zone T-60 w43357,79
13 w43357,80 T-90 Guide pipe T-90 Drying zone T-90 w43357,80
14 5320732 Strainer round w32291,01
15 5320153 Sliding block w43286,31
16 5320143 Foot l=245 w40252,31
17 5315686 Plastic foot 48x3-4 w718,0606
18 w41252,31 Curtain defence T-60,90 w41252,31
19 w36296,31 Reflector plate T-60,90 w36296,31
20 w726,0111 Pipe branching 50x88 3-muff w726,0111
21 w726,0110 Pvc bend 50x45 2-muff PP w726,0110
22 w726,0850 Pipe 50x3000 without muff PP w726,0850
23 5320158 Ratchet w43292,31
24 5320331 Shaft w43413,32
25 5320195 Lock ring SGA 8 A2 w701,1336
26 w43531,31 Washer attachment spring T-60,90 w43531,31
27 w43530,31 Attachment spring door T-60,90 w43530,31
28 5315515 Spring door 47N w713,1047
29 w43601,31 Spring support w43601,31
30 5315226 Curtain w33921,31
31 5315286 Bar for curtain w41709,31
32 w36175,31 Cover plate inside roof T-60,90 w36175,31
33 w43631,31 End plug w43631,31
34 5320156 Feeding clutch w43290,31
