Connections to be made
From the 3010S-LC harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• Connect the Pink wire to the Pink wire located in the HVAC harness
(ignore the writing on this wire, this is NOT a “mute” wire).
• Connect the Blue/White wire to the power antenna wire.
• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
Installing the Axxess interface
With the key in the off position:
• Connect the 3010S-LC harness into the interface, and then to the wiring harness
in the vehicle.
Initializing the Axxess interface
Attention: If the Axxess interface loses power for any reason,
the following steps will need to be performed again.
• Turn the key (or push-to-start button) to the ignition position and wait until the
radio comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the off
position, disconnect the interface, check all connections, reconnect the interface,
and then try again.
• Turn the key to the off position, and then start the vehicle.
• Cycle the A/C fan speed all the way to high, and then back to low.
•
Test all functions of the installation for proper operation, before reassembling the dash
.
Axxess interface installation 99-3010S-LC
