Metra Electronics 99-4644 - Chevrolet Camaro;Pontiac Firebird Dash Disassembly; Chevrolet Camaro;Pontiac Firebird 1982-1984 Disassembly; Chevrolet Camaro;Pontiac Firebird 1985-1992 Disassembly; Chevrolet Camaro 1997-2002 Disassembly

1. Remove(4)star-drivescrewsfromthedashtrim
bezelandremovethebezel.(FigureA)
2. Remove(4)screwssecuringthefactoryradioand
disconnectthewiring.
3. CutandremoveallmountingtabsonBracket#2
EXCEPTthosetabswithholes“A”.(FigureB)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.
Chevrolet Camaro/Pontiac
Firebird 1982-1984
Chevrolet Camaro
1997-2002
Chevrolet Camaro/Pontiac
Firebird 1985-1992
1. Remove(4)star-drivescrewsfromthedashtrim
bezelandremovethebezel.(FigureA)
2. Remove(4)screwssecuringthefactoryradioand
disconnectthewiring.
3. CutandremoveallmountingtabsonBracket#2
EXCEPTthosetabswithholes“B”.(FigureB)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.
1. Uncliptheradiotrimbezelandremove.(FigureA)
2. Remove(2)7mmhex-headscrewssecuringthe
factoryradioanddisconnectthewiring.
3. LocateBracketSet#10.(FigureB)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.
(Figure A) (Figure B) (Figure A) (Figure B) (Figure A) (Figure B)
“A”
“B”
Dash Disassembly 99-4644
