Metra Electronics 99-4644 - Chevrolet Caprice;Impala & Cavalier Dash Disassembly; Chevrolet Caprice;Impala 1994-1996 Disassembly; Chevrolet Cavalier 1982-1990 Disassembly

1. Remove(5)hex-headscrewsfrom
theashtraycavity.(FigureA)
2. Remove(4)hex-headscrewsfrom
thebaseofthedashtrimbezel.
(FigureA)
3. Unsnapthefuseboxcover 
andremove(1)hex-head 
screwexposed.
4. Remove(2)hex-headscrews
abovetheinstrumentcluster.
(FigureA)
5. Placethegearselectorin 
“D1“.Pulloutonthecluster
trimandremove.
6. Remove(1)hex-headscrew
exposedontheleftedgeofthe
dashtrimbezel.
7. Unclipthedashtrimbezel
(includingtheradiotrimbezel)
andremove.
8. LocateBracketSet#10.(FigureB)
Chevrolet Caprice/Impala
1994-1996
(Figure A)
(Figure B)
1. Remove(6)star-drivescrewsfrom
thedashtrimbezelandremove
thebezel.(FigureA)
2. Remove(2)screwsfrom 
thefactoryradioanddisconnect
thewiring.
3. Cutandremoveallmountingtabs
onBracket#4EXCEPTtabs“A”.
(FigureB)
Note: Identify mounting tabs by
the stamped letter on the back of
each tab.
Chevrolet Cavalier 1982-1990,
Cadillac Cimarron 1982-1988,
Pontiac Sunbird
with J-2000 panel style factory radio
1982-1988
(Figure A)
(Figure B)
“A”
“A”
Dash Disassembly 99-4644
