Metra Electronics 99-5722 - Kit Assembly; DIN Radio Provision with Pocket Installation

5
INST99-5722
KIT ASSEMBLY
DIN radio provision with pocket
1. Snap the pocket into the lower opening
of the radio/display trim panel . (Figure A)
2. Remove the metal DIN sleeve from the
aftermarket radio.
3. Slide the sleeve into the upper opening
of the radio/display trim panel and
secure by bending the metal locking
tabs down. (Figure B)
4. Slide the radio back into the sleeve until
it clicks in. (Figure C)
Continue to Axxess
Interface Installation
(Figure A) (Figure B) (Figure C)
