Metra Electronics 99-5841B - Kit Preparation

REV. 8/23/2018 INST99-5841B
KIT PREPARATION
3
(Figure A)
(Figure B)
1. Cut and remove the shaded area from
the sub-dash to allow clearance for the
aftermarket radio. (Figure A)
2. Attach the
(4) panel clips provided to
the
radio trim panel . (Figure B)
Continue to Kit Assembly
Remove shaded area
