Metra Electronics 99-5841B - Kit Assembly; ISO DIN radio provision with pocket; ISO DDIN radio provision

1.800.221.0932
|
MetraOnline.com
4
KIT ASSEMBLY
ISO DIN radio provision with pocket
1. Attach the
pocket to the radio brackets
using the (4) #8 x 3/8” Phillips screws
provided. (Figure A)
2. Remove the metal DIN sleeve and trim
ring from the aftermarket radio.
3. Slide the radio into the bracket/pocket
assembly, and then secure it using the
screws supplied with the radio.
(Figure B)
Continue to Axxess
Interface Installation
ISO DDIN radio provision
1. Attach the
brackets to the radio using
the screws supplied with the radio.
(Figure A)
Continue to Axxess
Interface Installation
(Figure B)
(Figure A) (Figure A)
