99-7860 DASH DISASSEMBLY
Honda Civic SI 2002-2005
D
isconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Remove the shift knob and unsnap
the shifter lever trim panel.
2
Using the offset tool remove (2) lower
bolts securing the center panel.
3
Unsnap and remove the dash trim
bezel and disconnect the wiring.
4
Remove (3) Philips screws securing
the climate control pod to the back of
the dash trim bezel and remove the
pod.
5
Remove (4) Phillips screws from each
side securing the factory head unit
and pocket to the bracket assembly
and remove.
6
NOTE: Removing the glove box and
the drivers side lower trim panel may
be necessary when removing the
shifter level trim panel when not
using an offset tool.
Continue to kit assembly.
