Metra Electronics 99-7860 - Double DIN Head Unit Provision

99-7860 KIT ASSEMBLY
A
B
C
Align the holes on the factory backet
assembly with the holes on the after-
market Double DIN head unit and
mount with the screws supplied with
the unit.
(Figure A)
1
Cut and remove the center rib (shad-
ed) from the Double DIN Trimplate.
(Figure B)
2
Snap the Double DIN Trimplate over
the head unit. (Figure C)
3
*
Note: Refer also to the instructions included with the aftermarket radio.
DOUBLE DIN HEAD UNIT PROVISION
Continue to final assembly.
Assembled kit.
