Metra Electronics 99-7860 - Stacked ISO Head Unit Provision

99-7860 KIT ASSEMBLY
A
B
Align the holes on the factory backet
assembly with the holes on the after-
market ISO head units and mount
with the screws supplied with the
unit.
(Figure A)
1
Snap the Double DIN Trimplate over
the head unit. (Figure B)
2
*
Note: Refer also to the instructions included with the aftermarket radio.
STACKED ISO HEAD UNIT PROVISION
Continue to final assembly.
Assembled kit.
