IX 3131 II - 9
2.2. LCD display description
figure 2
1.
Auto Auroranging indicator
2.
)
)
)
Beeper tone indicator for tolerance mode
3.
LCR L, C or R function indicator
4.
MAX, AVG, MIN Recording mode indicators
5.
MAX Maximum reading indicator
6.
AVG Average reading indicator
7.
MIN Indicates the minimum reading
8.
REL Relative mode indicator
9.
D Dissipation factor indicator
10.
Secondary display
11.
% Tolerance (percentage) indicator
12.
Q Quality factor indicator
13.
1 KHz Frequency indicator
14.
120 Hz Frequency indicator
15.
Mk
Resistance (Ohm) indicator
16.
µmH Inductance (Henry) indicator
17.
mµnpF Capacitance (Fara) indicator
18.
DH DATA HOLD indicator
19.
Tol Tolerance indicator
20.
1% 5% 10% Tolerance sorting (percent) indicator
SPECIAL INDICATION CHARACTERS
Indicates short connectors
Indicates open connectors
Indicates parallel mode
Indicates series mode
Indicates calibration mode
Indicates damaged or open fuse
