Metrix IX 3131 - Inductance Measurement; Capacitance Measurement

II - 12 IX 3131
3.3.2. Inductance measurement
• Press the "POWER" key to turn on the power.
• Press the function key to select Inductance test range.
• Connect the component leads to the test clip.
• Press frequency key to select 1KHz or 120Hz testing frequency.
• Read the display readings for inductance value and quality factor.
figure 6
3.3.3. Capacitance measurement
• Press « POWER » key to turn on the power.
• Press the function key to select Capacitance test range.
• Connect the test clip to the component leads.
•
Press frequency key to select 1 kHz or 120 Hz testing frequency.
•
Read the display readings for capacitance value and dissipation factor.
To avoid electrical hazards, discharge the capacitor to be tested before measuring.
figure 7
