Metrix MTX 3281 User Manual

Functional description
100.000-count Graphical Multimeters 15
Functional description (cont'd)
W REF
MTX 3283
Adjustment of the reference resistance value (W REF) between 1 Ω and
10,000 Ω for resistive power measurements:
The calculation performed is: (voltage measured)
2
/ W REF (unit W)
(current measured)
2
∗ W REF (unit W)
The adjustment procedure is the same as for the dBm reference resistance.
 Default value 50 Ω
ΩΩ
Ω .
W REF is used to calculate the resistive power (W) with
REF = W REF and to calculate the power (V ∗ A) when V (Ref) = W REF
Initialization of the
values
 Default values
The parameters of the configuration can be reinitialized to the default settings
in a single operation:
• Opening of the Configuration menu with the key.
• Selection of the "Default init"
function using the keys .
• Validation of initialization
using the
key.
Loading of the default values is confirmed by the following message:
General
Language : Fr Beep : on
Sleep : on Contrast : 50 %
Lighting : 2 min Communication : IR
IR baud : 9600 Configuration : basic
Energy 3281 : battery Energy 3282, 3283 : accu.
Accu. capacity : 2200 mAh
Measure
Filter : active Impedance : 10 / 20 M
dBm REF : 600 Ω W REF : 50 Ω
Favourite func.
MATH func.
Function : V Unit : none
Coef. A : 1 Coef. B : 0
MEM func.
Recording freq. : 1 s
No. of rec. 3281 : 158 No. of rec. 3282, 3283 : 1000
Main func.
V, A : AUTO, AC+DC Hz : 10 V range
Ω, Capacity : AUTO °C : °C, Pt 100
Message
Default values
loaded
Exit from the successive menus using
the key.

The language and the active main
function are not modified.
Configuration
Configuration
t
Func.
Func. MATH
Func. MEM
Set default values
☺
Default init
