3 Installation
807 Dosing Unit
￭￭￭￭￭￭￭￭
13
Figure 8 Marking rib on housing and distributor
Locking the housing
Figure 9
Locking the housing
Lock the housing as follows:
1
Hold the distributor in place.
2
Rotate the housing to the left (in clockwise direction).
Once all the parts are lined up with one another, the housing will
snap into place.
