OMNIS Titration Module – Overview
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
14
￭￭￭￭￭￭￭￭
Figure 2 OMNIS Titration Module – Rear
1
Bottle holder
2
Cable guide
On the side to the right. For Liquid Adapter
cable.
3
MSI connector
MSI = Metrohm Solution Identification. Con-
nection socket for Liquid Adapter cable.
4
MDL connector
MDL = Metrohm Device Link. Connection
socket for the connecting cable to the basic
unit.
5
Cable guide
Bottom right.
6
Cable guide
Bottom left.
7
Cable guide
On the side to the left. For rod stirrer cable
or electrode cable.
