Magnetic stirrer – Operation
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
68
￭￭￭￭￭￭￭￭
Mounting the tubings
￭ Tighten an FEP tubing (6.1805.100) into
port 1.
This tubing works as a dosing tubing.
Tighten the other end to the dosing tip.
￭ Tighten the second FEP tubing (6.1805.100)
into port 2.
This tubing works as a filling tubing. Tighten
the other end to the OMNIS Liquid Adapter.
￭ Firmly tighten the screws with the wrench
(6.2739.000).
7.3 Magnetic stirrer – Operation
The magnetic stirrer can be operated in two different ways:
￭ manually at press of the buttons on the instrument
– (see Chapter 7.3.1, page 68)
– (see Chapter 7.3.2, page 69)
￭ via the software
7.3.1 Switching the stirrer on and off
Switching the stirrer on and off
1
Switching on the stirrer
Press the key:
The stirrer begins stirring with the most recently used stirring rate.
2
Switching off the stirrer
NOTE
If the stirrer is running at a high stirring rate, we recommend to
reduce the stirring rate before switch-off.
