Mounting the cylinder unit
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
36
￭￭￭￭￭￭￭￭
5.3 Mounting the cylinder unit
NOTE
Default settings in the OMNIS Software
Port 1 is defined as dosing port and Port 2 as fill port in the OMNIS
Software default settings. The following instructions describe the
default setting.
If required, the ports can also be used differently. If the ports are used
differently from the default settings, the changes have to be entered
into the OMNIS Software in Properties ▶ Specific data of the dos-
ing unit.
NOTE
Before you mount the cylinder unit, the dosing unit has to be moved
into the exchange position.
The function for moving the dosing unit into the exchange position
can be found in the OMNIS Software in Manual control.
Preparing the mounting
1
Start the Manual control of the dosing unit in the OMNIS Software.
2
Start the Exchange position function.
Observe the splash warning and carry out the function.
Mounting the cylinder unit
NOTE
These instructions describe the default installation as defined in the
OMNIS Software.
Prerequisite
The dosing unit is in the exchange position.
