COMPONENT PART TYPE/VALUE QTY. DIAGRAM REFERENCE
Screw recessed head poz DIN 7985 M3x10 4
Screw recessed head poz DIN 7985 M4x30 4
Nut M3 6
Nut M4 4
Safety nut M4 1
Spring washer M4 4
Washer M4 12mmø DIN 9021 1
Spacer for fixing the front plate 5
Contact plate 1
RF protection box 1
Front plate w/5 screws for circuit board 1
Rear plate 1
Front foilv 1
PROCESSOR BOARD:
Printed circuit board Elprint AR075 1
Micro Module 16MM16 1 U1
Latch 74HC574N 3 U2, U3, U5
Port 74HC05N 1 U4
RS 232-driver MC145406P 1 U6
Voltage Reg. LM337LZ 1 U12
Voltage Reg. LM317T 1 U8
V-converter ICL7662CPA 1 U9
V-comparator Mc34064P-5 1 U10
V-converter NeI-D32-49 1 U11
EEPROM X24C02P 1 U13
Transistor BC547B 2 Q1Q2
Transistor BD140 1 Q4
Diode 1N4148 4 D1, D2, D5, D10
Diode 1N4002 1 D3
Schottky diode 1N5819 1 D4
Bridge 4A 200v 1 D9
LCD-display Optrex DMF 5005N-EW 1
Encoder Bourns ECWIJ-B24-BC0024 1 SW8
LED Gul 3mm Sie LY3360-K 1 D7
LED Rød 3mm Sie LR 3360-FJ 1 D8
Resistor 22R 1% 0.5W 2 R8, R17
Resistor 240R 1% 0.5W 1 Rll
Resistor 330R 1% 0.5W 2 R4, R5
Resistor 750R 1% 0.5W 1 R104
Resistor 1K0 1% 0.5W 1 R9
Resistor 2K2 1% 0.5W 1 R14
Resistor 6K8 1% 0.5W 1 R16
Resistor 10K 1% 0.5W 5 R2, R7, R12, R18, R19
Resistor 22K 1% 0.5W 2 R3R13
Resistor 100K 1% 0.5W 1 R1
Resistor pack 5x2K2 SIL 1 RP4
Resistor pack 8x4K7 SIL 1 RP2
Resistor pack 8x10K SIL 1 RP3
Resistor pack 8x47K SIL 1 RP1
Varistor 20V 1 R6
Trimpot 10K 1-tørn Cermet 1 R15
Multilayercond. 100nF 50V 6 C8
El.lytt cond. 10 F 25V 4 C2, C3, C5, C6
El.lytt cond. 220 F 25V 1 C7
El.lytt cond. 2200 F 25V 1 C1
Tantal cond. 1 F 35V 1 C4
EMI-Filter Murata
DSS306-91YSS102M1
19 FI1 - FI19
PCM-ClA slot 1 (U1)
Display-connection 4 pin Berg 71991-410 1 (DISP1)
8
