COMPONENT PART TYPE/VALUE QTY. DIAGRAM REFERENCE
Display-connection 20 pin Berg 71991-410 1 (DISP1)
Board pin base 16 pin 1 J1
Board pin base 10 pin 1 J2
Board pin base 26 pin 1 J3
Pin base for display (DISP1)
Pin base 36 pol 5 TP1-TP7
Screw clip basic part 2 pol 2 J4J5
Screw clip 2 pol 2 (J4J5)
Touch keys 7 SW1 - SW7 *1
Cover for touch keys 7 (SW1-SW7)
Safety holder Schurter 0031-8201 OGN 1 F1
Safety fuse 600mA Slow 1 (F1)
Heat sink Elfa 75-612-44 1 (Q4)
Screws M2 x 10 2
Nuts M2 2
Nylon screws M3 x 12 4
Nylon nuts M3 12
SAMPLING UNIT:
Printed circuit board Elprint AR-069 1
Op.amp High Current AD844AN 1 U21
Op.amp High Speed AD711JN 1 U25
Op.amp Railto Rail AD820AN 2 U13, U14
Op.amp Dual LMC662CN 2 U22, U23
Analog Multiplier AD834JN 1 U15
AiD-converter 12-Bit 250 kHz LTC 1272- 5CCN 1 U1
Octal Analog Switch Array DG485DJ 1 U24
Shift Register 74HC589AN 2 U2, U3
Quad Nand port 74HC00AN 1 U4
Opto Coupler CNW2611 8 U5- U12
Voltage Regulator LM317T 1 U16
Voltage Regulator LM317LZ 1 U17
Voltage Regulator LM2941T 1 U18
Voltage Regulator LM337LZ 1 U19
Voltage Regulator LM2991T 1 U20
Transistor 547BNPN 2 Q1, Q2
Transistor 560BPNP 2 Q4, Q5
Diode LL4148 12 D1 - D6, D8- D13
Zener diode 1N5335. 39V 2 D14, D15
Schottky diode PRLL5819 1 D7
Crystal 25 MHz 1 Y1
Resistor 4R7 1% 1/8W 2 R56, R57
Resistor 10R 1% 1/8W 4 R27, R34, R37, R58
Resistor 24R9 1% 1/8W 1 R24
Resistor 51R 1% 1/8W 2 R61, R72
Resistor 75R 1% 1/8W 2 R25, R26
Resistor 100R 0.25% 1/8W 4 R22, R23, R35, R36
Resistor 160R 1% 1/8W 1 R28
Resistor 249R 1% 1/8W 4 R42, R44, R46, R47
Resistor 390R 1% 1/8W 1 R90
Resistor 470R 1% 1/8W 18 R6 - R21, R64, R67
Resistor 750R 1% 1/8W 3 R5, R41, R55
Resistor 953R 1% 1/8W 2 R43, R45
Resistor 1K0 1% 1/8W 3 R54, R82, R83
Resistor 1K2 1% 1/8W 1 R75
Resistor 1K5 1% 1/8W 4 R48, R65, R73, R81
Resistor 1K8 1% 1/8W 4 R40, R52, R60, R71
Resistor 2K0 0.25% 1/8W 3 R38, R50, R77
Resistor 2K2 1% 1/8W 1 R89
Resistor 2K7 1% 1/8W 2 R63, R68
Resistor 3K3 1% 1/8W 1 R53
