METRON QA-ES User Manual

COMPONENT PART TYPE/VALUE QTY. DIAGRAM REFERENCE
Resistor 3K6 1% 1/8W 1 R76
Resistor 4K7 1% 1/8W 11 R49, R59, R62, R69, R70,
R78 - R80, R86 - R88
Resistor 10K 0.25% 1/8W 2 R30, R31
Resistor 18K 0.25% 1/8W 2 R39, R51
Resistor 22K 0.25% 1/8W 1 R29
Resistor 47K 0.25% 1/8W 2 R32, R85
Resistor 10M 1% 1/8W 2 R66, R74
Trimpot Multi. 10K 4 R1, R2, R3, R4
Chip ind. 10% 2 L1, L2
(Chip ind. 2% 2)
Cond Multil. lpF0 5% 63V 1 C22
Cond Multi. 47pF 5% 63V 2 C2, C3
Cond Multi. 100pF 5% 63V 3 C11, C46, C47
Cond Multi. 150pF 5% 63V 2 C5, C7
Cond Multi. 470pF 5% 63V 1 C6
Cond Multi. lnF0 5% 63V 2 C27, C28
Cond Multi. 10nF 10% 63V 20 C10, C11, C23-C26, C29,
C31 - C34, C36, C37 -
C39,C41, C42, C44, C45,
C60
Cond Multi. 100nF 10% 63V 8 C4, C8, C9, C12, C2, C35,
C71, C72
Tantal cond. 1,0 F 20% 15V 20 C30, C48, C49, C52, C53,
C56 - C59 C61 - C70
Tantal cond. 10 F 20% 15V 5 C14, C16, C17, C18- C20
El.lytt cond. 10 F 20% 50V 4 C13, C15, C54, C55
Condenser NC C40, C43, C50, C51
Printer board contact 6-polt hunn 2 J1, J2
SMB coax conn. Right angle PCB recept. 1 J4
Stifflist kort 16 pin 1 J3
18/36 pin base 36 pol (testpoints split) TP1 -TP18
Screw M3x6 Elzink Pan 3
Nut M3 Elzink 3
LOAD BOARD:
Printed circuit board Elprint AR-061B1 1
Voltage Regulator LM317T 1 U1
Resistance bridge 4A 200V GBU4D 1 D2
Resistor 3K0 5% 50W 1 R16
Resistor 9R1 5% 100W 1 R3
Resistor 15R 5% 100W 1 R4
Resistor 620R 5% 100W 1 R15
Resistor 47R 5% 175W 1 R5
Resistor 100R 5% 175W 4 R8, R9, R17, R18
Resistor 200R 5% 175W 4 R6, R7, R10, R11
Resistor 330R 5% 175W 1 R12
Resistor 470R 5% 175W 1 R13
Resistor 1K0 5% 175W 1 R14
Resistor 2R0 1% 10W 1 R1
Resistor 10R 0.1% 0,6W 1 R30
Resistor 26R1 0.1% 0,6W 2 R20, R22
Resistor 34R8 0.1% 0,6W 1 R21
Resistor 82R 0.1% 0,6W 4 R26 - R29
Resistor 100R 0.1% 0,6W 2 R19, R25
Resistor 51R 1% 0,5W 1 R31
Resistor 240R 1% 0,5W 1 R23
Resistor 750R 1% 0,5W 1 R24
El.lytt cond. 10 F 2,5V 25mm rad. 1 C3
El.lytt cond. 2200 F 25V rad. 2 C1, C2
Circuit driver UCN5842A 2 U2, U3
High voltage relay Günther 33911290246 1 K1
10
