COMPONENT PART TYPE/VALUE QTY. DIAGRAM REFERENCE

Relay 24V Takamisawa 10 K2 - Kll

Relay 24V 2-pol Takamisawa RY-24W-OH-K 2 K12, K13

(Relay 24V 2-pol Takamisawa RY-24W-K 2)

Toroid 3F3 125x75x5 mm ELFA

58-755-21

1 L1

SMB coax conn. Straight plug crimp 1

SMB coax conn. Straight PCB recept. 1 J13

Printer board contact 6-polt hannPhoe 1 J1, J2

Printer board clip 3-polt Phoe 1 J14

Safety holder Farn 134477 2 F1, F2

Safety fuse 600mAT Farn 150202 2 (F1), (F2)

High voltage cable 35 cm 10-/m @ 100 m 2

Coax. cable RG174 40 cm Farn 125326 1

Coax terminator Double leg right ang. 1

Plastic Spacer ENISO 3x25 38

Plastic Spacer ENISO 3x20 6

Nylon Screw M4x07x12 mm 36

Screw pin DIN 553 M4x22 mm 14

Dekk-kappe todelt 30

Bracket for power resistor 30
