Metso 7000 Series: 7150RR Series User Manual

IMO-R27 9
G
Figure 9
Insert Field Wrench
Parts List
3
"
& 4
"
(DN 80 & 100) =
Kit# 40-044-0154-00,
6
"
(DN 150) =
Kit# 40-044-0155-500
ITEM PART NAME QTY.
A Driver 1
C Plate 1
D Socket-Head
Cap Screw 2
E Threaded Rod 2
F Hex Nut 4
G Flat Washer 4
H Die Spring 2
C
E
G
H
F
F
A
D
8 EXPLODED VIEW - INSERT FIELD WRENCH
