8(19)
Serial Number
Actuator serial number can be written here.
3.1.1.2.3 Valve
Manufacturer
References a specific manufacturer, which is usually a
company name, that is responsible for the manufacture of
this Field Device.
Valve Type
Valve type indication. Options are
• Linear
• Rotary, part-turn
• Neles CV globe
• Undefined
Serial Number
Valve serial number can be written here.
3.1.1.3 Batch Information
Batch ID
Identifies a certain batch to allow assignment of equipment-
related information (e.g. faults, alarms ...) to the batch.
Batch Unit
Identifies the active Control Recipe Unit Procedure or the
related Unit (e.g. reactor, centrifuge, drier).
Batch Operation
Identifies the active Control Recipe Operation.
Batch Phase
Identifies the active Control Recipe Phase.
3.1.2 Settings
3.1.2.1 Assembly Related Configuration
NOTE:
The following parameters are assembly related. In or-
der to proper operation of the device, these parameter
values must match with the physical valve package.
See ND9000 Installation, Maintenance and Operating In-
structions for details.
Performance Level
Target performance level of the valve position control. Op-
tions are;
• Aggressive; In order to optimise the control perform-
ance the device immediate response to signal changes,
overshoots
• Over tuned; Fast response to signal changes, small
overshooting
• Optimum; Very small overshoot with minimum step re-
sponse time
• Stable; No overshooting, slow response to input signal
changes
• Max stability; No overshooting, deadband may increase,
slow but stable behaviour
Positioner Fail Action
Configuration of the action taken during the LOSS OF
SUPPLY POWER (supply pressure is available). This ac-
tion will also take place when the positioner software dis-
covers a fatal device failure. In these both cases the spool
valve feeds C1 (pneumatic connector) and releases C2
pressure. Options are;
• Undefined
• Close
• Open
Set value Close for double acting actuators. For single
acting actuators set value in the spring direction.
NOTE:
Perform valve calibration and tuning always when this
parameter has been changed.
Position Sensor Rotation
Defines relationship between the position sensor rotation
and valve action. Options;
• Undefined
• Standard : Clockwise to close
• Nonstandard : Counter clockwise to close
Actuator Type
Actuator type indication. Options are
• Undefined
• Double acting actuator
• Single acting actuator
Actuator Fail Action
Actuator fail safe position during LOSS OF SUPPLY
PRESSURE. This parameter is informational only.
• Undefined (Double acting actuator)
• Opening
• Closing
Valve Type
Valve type selection. Options are
• Linear
• Rotary, part-turn
• Neles CV globe
• Undefined
Dead Angle Compensation
The α0 setting is made for Metso Automation segment
and ball valves. This setting takes into account the “dead
angle” α0 of the ball valves. The entire signal range is then
used for effective valve opening 90° - α0.
Limit switches
This parameter defines either the limit switches are in-
stalled or not. Options are;
• Not installed (default)
• Installed
