Mhouse ws2s - Table of Contents; Step 2

1
GENERAL SAFETY WARNINGS AND PRECAUTIONS
STEP 1 2
KNOWLEDGE OF THE PRODUCT AND PREPARATION FOR
INSTALLATION
STEP 2 2
2.1 - PRODUCT DESCRIPTION AND INTENDED USE 2
2.2 - COMPONENTS USED TO SET UP A COMPLETE SYSTEM 3
PRELIMINARY CHECKS FOR INSTALLATION
STEP 3 3
3.1 - CHECKING SUITABILITY OF GATE TO BE AUTOMATED AND
RELATED ENVIRONMENT 3
3.2 - PRODUCT APPLICATION LIMITS 3
3.3 - PRODUCT DURABILITY 3
STEP 4 4
4.1 - PRELIMINARY CHECKS FOR INSTALLATION 4
4.2 - PREPARING ELECTRIC CABLES 4
INSTALLATION: ASSEMBLY AND CONNECTION
OF COMPONENTS
STEP 5 6
5.1 - INSTALLING THE GEARMOTOR WS1SK-WS1SC 6
STEP 6 10
6.1 - INSTALLING AND CONNECTING PHOTOCELLS PH100 10
6.2 - INSTALLING AND CONNECTING THE FLASHING LIGHT FL100 10
PROGRAMMING
STEP 7 12
7.1 - POWER SUPPLY CONNECTION 12
7.2 - INITIAL CHECKS 12
7.3 - RECOGNITION OF CONNECTED DEVICES 12
7.4 - RECOGNITION OF THE GATE LEAF OPENING AND CLOSING
ANGLES 12
7.5 - CHECKING THE RADIO TRANSMITTERS 12
7.6 - SETTINGS 12
TESTING AND COMMISSIONING
STEP 8 13
8.1 - TESTING 13
8.2 - COMMISSIONING 14
MAINTENANCE
STEP 9 14
DISPOSING OF THE PRODUCT 14
ADDITIONAL INFORMATION
STEP 10 14
10.1 - ADVANCED SETTINGS 14
10.2 - OPTIONAL ACCESSORIES 16
10.3 - ADDING OR REMOVING DEVICES 18
10.4 - MEMORISING ALL RADIO TRANSMITTERS 19
10.5 - TROUBLESHOOTING 21
10.6 - DIAGNOSTICS AND SIGNALS 21
TECHNICAL SPECIFICATIONS OF PRODUCT
COMPONENTS 24
APPENDIX 1 - EC declaration of conformity 27
OPERATING GUIDE
STEP 11 29
11.1 - SAFETY INSTRUCTIONS 29
11.2 - GATE CONTROL 29
11.3 - MANUALLY RELEASING OR LOCKING THE GEARMOTOR 29
11.4 - MAINTENANCE OPERATIONS ADMISSIBLE TO THE USER 30
11.5 - REMOTE CONTROL BATTERY REPLACEMENT 30
11.6 - REMOTE CONTROL SUPPORT INSTALLATION 30
APPENDIX 2 - EC declaration of conformity 31
CONTENTS
