General
capaNCDT 6220/6222/6230
Setup, Connection Options
Power supply and signal output are provided via plug con-
nectors on the front of the controller.
SPS
SCACx/4
Ethernet
EtherCAT
(optional)
CCxxx
LAN cable
RJ-45 connectors
Controller
Sensor
PC
Run
X1
X2
Ether
CAT
PS 2020
PC6200-3/4
Ammeter/Voltmeter
