A - Power cable, 90-250V-50-60Hz
B - Enable input (dosing consent)
(110Vac; 230Vac; upon request 24V).
OPTIONAL
C - Alarm output connector (3 and 4 contacts).
( 5A 250Vca/30Vdc)
NORMALLY OPEN. OPTIONAL.
D - Level probe connector (3 and 4 contacts).
OPTIONAL.
E - Connector for mA input (contacts 1 (-) and 2
(+)) / pulses from water meter (contacts 3 and 4).
F - ON_OFF switch. OPTIONAL
DEFAULT SETTINGS
PASSWORD = Not programmed
Delay On: 0 minutes
Enable (optional): active
Broken Hose (optional): active
• Dosing: mA
• mA Min: 4.0mA
• % Min: 10%
• Dos.Min: deactive
• mA Max: 20.0mA
• % Max: 100%
• Dos.Max: active
•
DEFAULT SETTINGS RESTORE
3sec
Keep pushing for 3 seconds the ENTER / MENU button to
enter into the programming menu.
Move the cursor > to Utility by pressing ▼. Push ENTER
button to enter the submenu.
Push ▼ button to move the cursor to “Reset”.
Push ENTER button to confirm.
By pushing the ▼ button choose “YES” to confirm and push
ENTER button.
Automatically the pump restores the factory settings.
Press the ESC button for 3 seconds to exit programming.
